Mine Spec 5 Rustproofing (Underground)

Beam Underground Mine Spec 5 Rustproofing Treatment is a comprehensive bituminous, wax and dry film rust treatment designed to combat corrosion in harsh conditions where the standard mining specification is inadequate. Spec 5 includes additional high risk areas such as the exhaust system and the electrical and hydraulic fittings / connections. This level of rust protection is suitable for vehicles engaged in underground mining and would be the minimum requirement for those used in salt and fertiliser works and coastal shipping facilities. See full description below:


Endrust UB302B is a heavy-duty bituminous, thixotropic, anticorrosive sealant, ideally suited for the complete coating of the underside of all vehicle types. Typically the areas sprayed include:
  • The complete underbody and chassis.
  • Lower cavities of the front and rear guards.
  • Wheel arches, fuel, air, and hydraulic tanks
  • Transfer casing, driveline, axles, and differentials.
  • Suspension components, brake housings, and steering arms.
  • Fixing points for tow bars, bull bars, and side steps.
  • Internal Footwells and floor.
Endrust ML602 is a fogging style “Cavity Wax” purpose-designed to float and coat inside box sections and hard-to-access panels.
  • Inside Door cavities, Pillars, Rocker Panels and Box Sections.
  • Inside Bonnet & Boot lid stiffeners and tailgate areas.
  • Inside Chassis rails
Endrust RX CLEAR is a 1K anti-corrosive Clearcoat that is spray applied to the entire engine compartment including:
  • all painted areas plus nuts, bolts, and fixings.
  • upper and lower radiator supports.
  • behind the headlights and grill.
  • particular attention to seams, and joints plus around and beneath the Battery.
Denso Tape is a corrosion-resistant, fire-retardant wax tape that is hand-wrapped around the following components.
  • All accessible hydraulic and Fluid fittings.
  • All external electrical wiring connections.

Options and Related Treatments

  • CATIII Electronic Anti-Corrosion System – For a complete anti-corrosion solution, you should consider the advantages of installing a CAT System. Electronic Anti-Rust Systems can protect all those areas of your vehicle that cannot or should not be sprayed with chemical rustproofing – Please enquire.
  • Underbody or Upperbody only treatments may be more suitable in some situations – please enquire.
  • Endrust UB702 is a High Build 2K epoxy mastic for coating chassis and underbody areas. Beam highly recommends this coating as an upgrade replacement for the traditional bituminous-based under-body coating used in this specification. See Ultratect Surface Mining Spec 8.
  • Some or all of the exterior painted surfaces can be coated with our Endrust PSX CLEAR 2K Teflon/Polyurethane Clearcoat to provide long-term protection against attack by water, acids, and most chemicals. This product is ideal for Roofs, Gutters, Doors, Bonnets, Side steps, and Bullbars in fact its applications are almost unlimited. Endrust PSX CLEAR is UV stable (will not go yellow) and will not significantly change the appearance of the substrate. It can also be removed or repaired easily at any time if required.
  • Rhino Lining – Polyurethane spray-on tray and surface coating – Ideal for inside load areas and to encapsulate and permanently protect high-impact areas such as bull bars, side steps, internal floor pans, mudguards, wheel arches, chassis rails, and most underbody components. Rhino Lining can be sprayed to any thickness, is slip-resistant, prevents Rust and Corrosion, is Waterproof and chemical resistant, and will not be damaged by flying debris or rocks – please enquire about how our Rhino Lining product can protect your vehicle.

Application Time : (3 DAYS)

(Note: The above specification was last revised 1/3/2024 and should be used as a guide only. Some procedures may be altered or omitted for specific vehicle types or due to special customer requests. Beam reserves the right to alter this specification at any time without notice if new products or techniques become available.)
